Description
Product Features
Advanced Functionality
Equipped to handle the latest technology requirements seamlessly
Reliable Build Quality
Designed with premium materials for enhanced durability and longevity
Enhanced Specifications
Ideal for a wide range of applications, from gaming to content creation
Product Specifications
CPU
Socket: AMD Socket AM5
CPU Support: AMD Ryzen 9000 and 8000 and 7000 Series
Memory
Slots: 4 x DIMM
Max Memory: 256GB
Memory Type: DDR5
Speed: Up To 8000+MT/s OC With Ryzen 9000 and 8000 and 7000 Series Processors
ECC: ECC and Non-ECC, Un-buffered DIMM
Architecture: Dual Channel Memory Architecture
Profiles: AMD Extended Profiles For Overclocking EXPO
Profile: ASUS Enhanced Memory Profile AEMP
Graphics
HDMI: 1 x HDMI Port
USB4 Display Output: 2 x USB4 40Gbps Ports Support USB Type-C Display Outputs
HDMI Max: 4K@60Hz As Specified In HDMI 2.1
USB Type-C Display Max: Max 4K@60Hz As Specified In DisplayPort 1.4a
Expansion Slots
Ryzen 9000 and 7000: 1 x PCIe 5.0 x16 Slot Supports x16 Mode
Ryzen 8000: 1 x PCIe 4.0 x16 Slot Supports x8/x4 Mode
X870 Chipset: 2 x PCIe 4.0 x16 Slots Support x1 Mode
Storage
M.2 and SATA: Supports 4 x M.2 Slots and 2 x SATA 6Gb/s Ports
M.2_1: Key M, Type 2280, Supports PCIe 5.0 x4 Mode With Ryzen 9000 and 7000 Series
M.2_1: Key M, Type 2280, Supports PCIe 4.0 x4 Mode With Ryzen 8000 Series
M.2_2: Key M, Type 2242/2260/2280, Supports PCIe 4.0 x4 Mode
M.2_3: Key M, Type 2280, Supports PCIe 4.0 x4 Mode
M.2_4: Key M, Type 2280, Supports PCIe 3.0 x2 Mode
SATA: 2 x SATA 6Gb/s Ports
RAID: AMD RAIDXpert2 Technology
RAID Ryzen 9000: RAID 0/1/5/10
RAID Ryzen 8000: RAID 0/1
RAID Ryzen 7000: RAID 0/1/10
Ethernet
LAN: 1 x Realtek 2.5Gb Ethernet
Protection: ASUS LANGuard
