PERFORMANCE

Processor

Intel® Core™ i5-14400, 10C (6P + 4E) / 16T, P-core 2.5 / 4.7GHz, E-core 1.8 / 3.5GHz, 20MB

Graphics

Integrated Intel® UHD Graphics 730

Chipset

Intel® B760 Chipset

Memory

1x 8GB UDIMM DDR5-4800

Memory Slots

Two DDR5 UDIMM slots, dual-channel capable

Max Memory

Up to 64GB DDR5-5600

Storage

512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0

Storage Support

Up to three drives, 1x 3.5"HDD + 1x 2.5"HDD + 1x M.2 SSD • 3.5" HDD up to 2TB • M.2 SSD up to 1TB • 2.5" HDD bay is only for customer self upgrade

Card Reader

3-in-1 Card Reader

Optical

None

Audio Chip

High Definition (HD) Audio, Realtek® ALC623-CG codec

Speakers

2Wx1

Power Supply

180W 85%

DESIGN

Keyboard

USB Calliope Keyboard, Black, English (UK)

Mouse

USB Calliope Mouse, Black

Optional Bay

None

Expansion Slots

One PCIe® 3.0 x16, full-height, length = 233.6mm, height = 117.5mm

One PCIe® 3.0 x1, full-height, (length = 185mm, height = 100mm) or (length = 118mm, height = 110mm)

Two M.2 slots (one for WLAN, one for SSD)

Case Color

Black

System Fan

None

Toolless Chassis Screw

Toolless Chassis Screw

Pen

Pen Not Supported

Form Factor

Tower (13.6L)

Dimensions (WxDxH)

145 x 294 x 340  mm (5.71x 11.57 x 13.39 inches)

Weight

Around 5.6 kg (12.35 lbs)

CONNECTIVITY

Ethernet

RTL8111K, 1x RJ-45

WLAN + Bluetooth

None

WWAN

Non-WWAN

Front Ports

1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with data transfer and 15W charging

4x USB-A (USB 5Gbps / USB 3.2 Gen 1)

1x headphone / microphone combo jack (3.5mm)

1x microphone (3.5mm)

Rear Ports

1x DisplayPort™ 1.4a (HBR2)

4x USB-A (Hi-Speed USB / USB 2.0)

1x HDMI® 2.1 TMDS

1x VGA

1x Ethernet (RJ-45)

1x line-out (3.5mm)

Optional Rear Ports (configured)

None

SECURITY & PRIVACY

Security Chip

Discrete TPM 2.0, TCG certified

Physical Locks

Kensington® Security Slot™

Padlock Loop

Smart Cable Clip

None

Chassis Intrusion Switch

Chassis Intrusion Switch

MANAGEABILITY

System Management

None
