Product Features

Processor Support: Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors for LGA 1700 socket

Memory Support: Supports DDR5 Memory, Dual Channel DDR5 7800+MHz OC

Enhanced Power Design: 16+1+1 DRPS with 80A SPS, dual 8-pin CPU power connectors, Core Boost, Memory Boost

Premium Thermal Solution: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and M.2 Shield Frozr are built for high performance system and non-stop gaming experience

High Quality PCB: 6-layer PCB made by 2oz thickened copper and server grade level material

Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2x2

Intel Turbo USB: Powered by Intel USB 3.2 Gen2 controller, Turbo USB ensures an uninterrupted connection with more stability and fastest USB speeds

Networking: 2.5G LAN with Wi-Fi 7 Solution delivers a secure, stable and fast network connection

Audio: AUDIO BOOST 5 for studio grade sound quality for an immersive gaming experience

Product Specifications

Model: PRO Z790-A MAX WIFI

Socket: Intel LGA1700 Socket

Processor Support: Intel Core 14th/ 13th/ 12th Gen, Intel Pentium Gold, Celeron for LGA 1700 socket

Memory: DDR5 Dual Channel Up To 7800+MHz OC

Power Design: 16+1+1 80A Power

Expansion: PCIe 5.0 slot

Storage: M.2 Gen4, Lightning Gen 4 x4 M.2

USB: USB 3.2 Gen2x2, Intel Turbo USB 3.2 Gen 2

Networking: Wi-Fi 7, 2.5G LAN

Audio: Audio Boost 5

PCB: 6-layer PCB, 2oz thickened copper, server grade level material

Thermals: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads, M.2 Shield Frozr
